Model : ST-2000C; ST-5000C; ST-6000C
- Sterilization Volume : 1.8 L; 5.2 L; 6.0 L
- Operating Temperature Range : 115 °C ~ 135 °C
- Display Accuracy : 0.1 ℃
- Sizes(WxDxH)(mm) : 570x415x170; 580x460x190; 580x460x190
Cassette Sterilizer
Cassette sterilizers are designed for fast, efficient sterilization in a compact form, ideal for use in patient-facing spaces like exam rooms. They quickly sterilize instruments between appointments without compromising on care—delivering powerful performance while remaining gentle on delicate and high-value tools. Unlike bulkier autoclaves, cassette models use only a measured amount of heated distilled water per cycle, offering greater efficiency, lower water consumption, and reduced operating costs.
Cassette Sterilizer Features:
- Available in multiple capacities to suit various medical and laboratory environments.
- Wide temperature range ensures stable and reliable sterilization performance.
- 0.1℃ display accuracy guarantees precise temperature control for effective sterilization.
- Compatible with various water types, including ultrapure, deionized, distilled, and purified water.
- Self-diagnostic system halts operation and displays an error code when a fault is detected.
- Fast cycles as short as 6–7 minutes improve workflow efficiency.
- Water shortage alarm alerts users to prevent incomplete sterilization.
- Compact and lightweight, ideal for temporary storage and easy portability.
Cassette Sterilizer Specifications:
| Model | ST-2000C | ST-5000C | ST-6000C |
| Sterilization Volume | About 1.8 Liters | About 5.2 Liters | About 6.0 Liters |
| Tank Volume | 3.4 Liters | 3.4 Liters | 3.4 Liters |
| Maximum Operating Pressure | 242 kPa | ||
| Operating Pressure Range | 42 kPa ~ 212kPa | ||
| Maximum Operating Temperature | 138° C | ||
| Operating Temperature Range | 115 °C ~ 135 °C | ||
| Display Accuracy | 0.1 ℃ | ||
| Water | Ultra-pure water, deionized water, laboratory water. | Ultra-pure water, deionized water, laboratory water, distilled water, purified water. |
Ultra-pure water, deionized water, laboratory water, distilled water, purified water. |
| Voltage/Frequency | AC 220V/50 Hz | ||
| Input Power | ≤1.3 kVA | ||
| Atmospheric Pressure Range | 70.0 kPa to 106.0 kPa | ||
| Ambient Temperature Range | + 5 °C ~ + 40 °C | ||
| Steam Generator Power | 1.2 kVA ± 5% | ||
| Fuse | F8AL250V phi 5 x 20 mm | ||
| Safety Valve Setting Pressure | 0.25 MPa | ||
| Equipment Working Medium | Water Vapor | ||
| Working Relative Humidity | ≤85% | ||
| Normal Use Place | Work room | ||
| Run Mode | Run Intermittently (≤6 cycles/hour) | ||
| Sizes (WxDxH)(mm) | 570x415x170 | 580x460x190 | 580x460x190 |
| Shipping Size (WxDxH)(mm) | 700x580x580 | 700x580x580 | 700x580x580 |
| N.W./G.W. (kg) | 35/50 | 45/60 | 45/60 |
Applications of Cassette Sterilizer:
- Dental Clinics: Rapid sterilization of dental instruments and tools to ensure clinical hygiene and patient safety.
- Medical Facilities: Effective sterilization of surgical tools, syringes, needles, and implants.
- Beauty & SPA Centers: Ensures hygienic sterilization of beauty tools, needles, and instruments.
- Laboratories & Research: Sterilizes labware like petri dishes, test tubes, and pipettes to prevent contamination and ensure result accuracy.
How the cassette sterilizer works:
Once the sterilization program is selected and started, the steam generator heats to the optimal temperature. A measured amount of distilled water is pumped in and instantly converted to steam, which is evenly distributed throughout the cassette containing contaminated instruments. As the steam fills the cassette, it displaces and removes all cold, unclean air to ensure effective sterilization.
